Dakota Universal ION Series Oval 5 Gauge Kit Speedometer Tach ION-50-1

Description

Dakota Universal ION Series Oval 5 Gauge Kit Speedometer Tach ION-50-1

ION SERIES, 5 Gauge Kit
from Dakota Digital
ION-50-1 (MPH) or ION-50-2 (KPH)

Please note: This item may have a build time of approx 1-3 weeks before it goes out. You can still purchase it now and it will go out as soon as it is ready. eBay’s wording of “available” does NOT mean it is in stock, it is available for purchase. We apologize for any confusion! If you would like an updated time estimate, please contact us before you purchase. For domestic orders, it will get sent to you directly from the manufacturer. For international and Canada orders, it will get sent to our shop first, then we will send it out to you.

This listing is for one ION-50-1 (MPH) OR one ION-50-2 (KPH) 6 Gauge Kit from Dakota Digital.

Description from Dakota Digital:

The Ion Series of instrumentation from Dakota Digital offers the latest in modern styling, cutting edge technology and the utmost digital accuracy for your custom ride! The Ion Series was designed to set itself apart from the standard gauge look offering sleek, streamlined instrumentation to match the theme of today’s high tech vehicles. Enclosed in fully machined aluminum housings the Ion Series offers a truly astounding look to match the superb performance.

Two gauge sizes: Small is 3-1/4″ x 1-5/8″ and Large is 7″ x 3-1/16″.

Includes:

• ION-01-6 Speedometer-Tachometer.
• ION-03-1 Oil Pressure.
• ION-04-1 Water Temp.
• ION-05-1 Voltmeter.
• ION-06-1 Fuel Level.

Oil Pressure, Water Temp, Speed Senders Included.

ION-01-6 – Digital Speedometer/Tachometer Combo:

• Adjustable 255 MPH (KPH available) speedometer calibration is adjustable for nearly any gearing or tire size combination.
• Compatible with both electronic and cable drive applications.
• Odometer with resettable trip odometer.
• Quick response numeric tachometer with adjustable shift point warning.
• Easy Tachometer calibration for a wide range of cylinder combinations from 1- 15 cylinders without the use and hassle of bulky coils.
• Gear Position Indicator with optional sender GSS-2000 (available to purchase in our store).
• Adjustable shift point indicator with warning.
• Various indicators can also be displayed such as Turn Signal, High Beam.
• Several performance calculations include: 0- 60 time, high speed & high RPM recall, 1/4 mile time and speed.
• Easy push button calibration.

ION-03-1 – Oil Pressure:
Range: 0- 150 psi
Resolution: 1 psi

ION-04-1 – Water Temp:
Range: 0- 300°F or 0- 150°C
Resolution: 1°F or 1°C

ION-05-1 – Voltmeter:
Range: 0- 17.0 VDC
Resolution: 0.1 VDC

ION-06-1- Fuel Level:
Range: 0- 99% or gallons remaining

DON’T FORGET: When you make your payment, be sure to include your choice of the following:

• ION-50-1 (MPH) or ION-50-2 (KPH)
• Teal or Blue Display
• Chrome or Satin Bezel

Warning: This product may contain a chemical known to the state of CALIFORNIA to cause cancer, birth defects or other reproductive harm.
